STANDARDPhysics-Alternating Current
STANDARD Physics Phase Relationship MCQ Question
Type: MCQ-conceptual-Medium-Class 12
The phase relationship between current and voltage in a pure resistive circuit is best represented by
A
Option 1: V, I
B
Option 2: V, I
C
Option 3: V, I
D
Option 4: V, I
Correct Answer
Option C
Detailed Explanation
In a pure resistive circuit, current and voltage both are in phase. Hence, graph (c) is correct.
