STANDARD Physics Combination of Resistors MCQ Question
Equivalent resistance of the given network between points A and B is
31/5 Ω
41/5 Ω
36/5 Ω
49/5 Ω
Correct Answer
Detailed Explanation
In each segment, the combination of 3 Ω and 2 Ω resistances are connected in series separately. R' = 3 + 3 = 6 Ω and R'' = 2 + 2 = 4 Ω. R' and R'' are connected in parallel. The equivalent resistance for each segment is calculated and then summed for the total resistance.
