NEET Physics Internal Resistance of Cells MCQ Question
A cell having an emf ε and internal resistance r is connected across a variable external resistance R. As the resistance R is increased, the plot of potential difference V across R is given by
Correct Answer
Detailed Explanation
As R increases, the potential difference V approaches the emf ε, which is represented by the graph in option (2).
